Leupold

Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296

(No reviews yet) Write a Review
SKU:
ISS7933
UPC:
030317016357
MPN:
173296
  • Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296
  • Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296
  • Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296
  • Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296
  • Leupold Mark 5HD 3.6-18x44 FFP Riflescope: 35mm Tube, M5C3, TMR Reticle, Model 173296
  • TMR (Mk) Reticle
Expands on existing MIL Dot reticle design
Uses hash marks instead of dots for increased ranging and holdover precision
Provides aiming points for both wind and bullet drop compensation
1 MIL is approximately 3.6 inches at 100 yards
Hash marks are spaced 0.5 MIL apart, transitioning to 0.2 MIL spacing on the outer edges
Not caliber specific
Front (first) focal plane
MIL based systems are the current military standard
Our Price: $3,334.00

Description

Pick up a Mark 5HD™ 3.6-18x44mm and you'll feel the difference. It's up to 20 ounces lighter than other riflescopes in its class, giving you an advantage in the field or at the range. The versatile 3.6-18x magnification range helps you engage close targets, while also giving you the flexibility to reach out to long distances. With three revolutions of elevation adjustment and multiple reticle options, this scope will max out the performance of the latest long-range rifles and ammunition, guaranteed.

Built around Leupold’s Professional-Grade Optical System, the Mark 5HD offers unmatched light transmission that’s designed to outperform in the most challenging lighting conditions. Its industry leading glare reduction provides a clear image in harsh, direct light, while the resolution and clarity will meet the demands of any professional guide or shooter. Ergonomically designed with more tactile and audible click adjustments, larger numbers, and a high-speed throw lever, the Mark 5HD is built to put accurate fire downrange faster.

The unique combination of features, durability, and professional-grade optical performance guarantees that the Mark 5HD can handle any challenge you throw at it. It's 100% waterproof and fogproof, and like all Leupold® riflescopes, it's designed, machined, and assembled in the USA and guaranteed to perform for life.

  • 5:1 Zoom Ratio
    A versatile 5:1 zoom ratio gives you 5 times more magnification at high power than at low power (model magnification ranges may be available in powers of 5x: 1-5, 2-10, 3-15, 4-20, etc.), so you can adjust your magnification to find the perfect balance between magnification and field of view for any situation. The larger the zoom ratio, the more versatile one scope can be.

  • Professional-Grade Optical System
    Leupold’s Professional-Grade Optical System offers unmatched light transmission that’s designed to outperform in the most challenging lighting conditions, industry-leading glare reduction for a clear image in harsh, direct light, and the resolution and clarity that professional guides and shooters demand in the field.

  • Side Focus
    The side focus adjusts the scope's parallax, making the reticle clearer and have less perceived movement when you're shooting at different distances.

  • M5C3 ZeroLock® Adjustments
    These low-profile dials are available on select models and provide up to 30-MILs of adjustment in 3 revolutions and 0.1 MIL clicks. Visual and tactile revolution indicators ensure you don’t get lost in the travel. The ZeroLock® feature prevents inadvertent adjustments and ensures accurate return to zero.

  • First Focal Plane
    In First Focal Plane (front focal plane) scopes, the reticle grows and shrinks at the same rate as the target when you adjust the magnification. This allows you to accurately use the reticle feature at any magnification setting. These reticles are ideal in tactical situations but can also aid in range estimation for hunters and target shooters.

  • Zero Lock Dial
    The ZeroLock® system eliminates accidental dial movement by locking it in place.

  • Zero Stop
    The ZeroStop system creates a backstop when returning the dial back to zero, so you don't accidently turn the dial a full revolution in the wrong direction.

  • Waterproof, Fogproof, & Shockproof
    Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures, elevation changes, and shocks, so the internals of the optics stay moisture free and crystal clear for life.



TMR (Mk) Reticle

  • Expands on existing MIL Dot reticle design
  • Uses hash marks instead of dots for increased ranging and holdover precision
  • Provides aiming points for both wind and bullet drop compensation
  • 1 MIL is approximately 3.6 inches at 100 yards
  • Hash marks are spaced 0.5 MIL apart, transitioning to 0.2 MIL spacing on the outer edges
  • Not caliber specific
  • Front (first) focal plane
  • MIL based systems are the current military standard



SKU ISS7933
MPN 173296



Badge Best Seller
Adjustable Objective No
Elevation Adjustment Type M5C3
Locking Dial Yes
Revolution Indicator Yes
Rezero Type Set Screw
Windage Adjustment Type Capped
Custom Dial System (CDS) No
Custom Dial Compatible Yes
BDC Dial Included No
Reticle Type First Focal Plane
Reticle FFP TMR (Mk)
Magnification Type Variable
Illuminated No
Nightvision Compatible Illumination No
Daylight Bright Illumination No
Motion Sensor Technology (MST) No
Electronic Reticle Level No
Guard-ion Lens Coating No
Weight (oz) 26
Elevation Adjustment Value per Click 0.1Mil
Elevation Adjustment Range (MOA) 100
Elevation Adjustment Range (MIL) 29
Elevation Adjustment Range (cm @ 100m) 291
Elevation Adjustment Per Revolution 10.5 MIL
Elevation Dial Travel Limit 30MIL
Windage Adjustment Value per Click 0.1Mil
Windage Adjustment Range (MOA) 80
Windage Adjustment Range (MIL) 23
Windage Adjustment Range (cm @ 100m) 233
Windage Adjustment Per Revolution 10 MIL
Magnification Max 18
Magnification Min 3.6
Objective Lens Diameter (mm) 44
Linear FOV Low Mag (ft@100yds) 28.3
Linear FOV High Mag (ft@100yds) 5.8
Angular FOV Low Mag (Degrees) 5.4
Angular FOV High Mag (Degrees) 1.1
Eye Relief Low Mag (in) 3.5
Eye Relief High Mag (in) 3.8
Minimum Parallax-Free Distance (yd) 50



View AllClose

Additional Information

Product:
Riflescope
Series:
Mark 5HD
Magnification:
3.6 - 18x
Objective Lens Diameter:
44 mm
Tube Diameter:
35 mm
Focal Plane:
FFP
View AllClose
